Genset TP110T 100 KVA

TECHNICAL SPECIFICATIONS
DIESEL GENERATING SET 400/230V-50Hz-3Phase
WEIGHT AND DIMENSIONS
STANDARDS:
Genset: GB/T2820—2009,ISO8528
Alternator: STAMFORD, UCI274C
Diesel Engine: PERKINS , 1104C-44TAG2
Standby Power: Continues running at variable load for duration of an emergency. No overload is permitted on these ratings.
Prime Power: Continues running at variable load for unlimited periods with 10% overload available for 1 hour in any 12 hour period.

Genset Perkins TP110T 100 KVA. Anda membutuhkan Genset 100 KVA ?, Kami menjual Genset TP110T untuk kebutuhan Genset kapasitas 100 KVA. Berikut ini adalah spesifikasinya :

Model Engine Standby Rated
KVA KW KVA KW
TP110T 1104C-44TAG2 110 88 100 80

DIESEL GENERATING SET 400/230V-50Hz-3Phase

STANDARDS:
Genset: GB/T2820—2009,ISO8528
Alternator: STAMFORD, UCI274C
Diesel Engine: PERKINS , 1104C-44TAG2
Standby Power: Continues running at variable load for duration of an emergency. No overload is permitted on these ratings.
Prime Power: Continues running at variable load for unlimited periods with 10% overload available for 1 hour in any 12 hour period.

CONFIGURATION:
Standard: Engine, alternator, cooling system, Base frame (excluding fuel
tank), shock absorber, air inlet system, control box (including mains floating
charge), plastic fan blades (when the engine and water tank do not bring).
Optional: Base frame (including fuel tank), water jacket heater, fuel water
separator, fuel heater, fuel level sensor (only supporting underframe tank),
switch box (with switch), power switch, the water level sensor, motor anti
condensation heater, automatic fueling system (only supporting base frame
including fuel tank), battery frame.
Accessories: Silencer, bellow, exhaust silencing system accessories (with the
matching engine), regular battery, starting cord assembly, data of gen-set,
random tool (with the matching engine.
Model
TP110T
Power(ESP)
kVA/kw
110/88
Power(PRP)
kVA/kw
100/80
Rated Voltage
V
400
Rated Current
A
159
Rated rotation speed
r/min
1500
Power Factor
0.8
Fuel Consumption
Litre/hour
22.6
Fuel Tank Capacity
Litre
Open Type :141 / Silent Type:315
Noise level
dB(A)@7m
Silent Type: 76±2
GEN-Set
Dimension ( L*W*H )
Weight
Open Type
1935mm*815mm*1310mm
1148 Kg
Silent Type
3146mm*1106mm*1700mm
1960 Kg

Brand

Perkins
